Headline Compact filter housing 340 Bar 316 Viton 1/4"NPT-F 1/4"NPT-F
Compact filter housing
The Headline 110 Series filter housings are compact instrumentation filter assemblies designed for the removal of particulate contamination from gas and liquid process streams. These housings provide reliable protection for sensitive downstream equipment such as regulators, valves, analyzers, and flow instrumentation. Manufactured from corrosion-resistant materials including 316 stainless steel and specialty alloys, the series offers excellent mechanical strength and long-term durability in demanding industrial environments. The compact design supports easy installation in confined system layouts while maintaining dependable sealing performance and service accessibility. Typical applications include analytical systems, sampling systems, gas distribution panels, hydraulic systems, and general process instrumentation requiring efficient and reliable inline filtration.
Body material:
Seat:
Working pressure:
Size:
Volume:
SS316L
Viton
340 Bar
110
20
Connection A size:
Connection A type:
Connection A gender:
Connection B size:
Connection B type:
Connection B gender:
Connection C size:
Connection C size:
Connection C type:
Connection C gender:
1/4"
NPT
female
10mm
od
female
1/4"
NPT
male
• Pressure rated up to 700 bar (10,000 psi)
• Temperature rated up to 200 °C (500 °C with PTFE S-type gasket)
• 316L stainless steel construction, weld-free design
• Available with 1/8" or 1/4" NPT ports, with or without drain
• Compact internal volumes: 26 cc (110HP) and 40 cc (120HP)
• Compatible with PTFE, stainless steel, and disposable filter elements
• NACE MR-01-75 compliant
• Built to BS5500 pressure vessel standards
• Optional support cores and mounting brackets
