117G

1/4"
-
NPT
-
female
Compact filter housing

The Headline range of low pressure stainless steel housings is extended by the use of Pyrex glass bowls. This allows the condition of the filter element to be monitored visually. This is important in systems subject to slugs of water, especially those under negative pressure requiring manual draining. Guards are fitted as standard to all Pyrex bowls.

• Standard seals: Viton (other materials available on request)
• Port size: 1/4" NPT
• Drain size: 1/8" NPT
• Maximum operating pressure: 7 bar
• Maximum operating temperature: 100 °C
• Mounting brackets and support cores available (see product data sheets)
• Compatible with disposable filter elements: 12-32-xx
• Compatible with stainless steel elements: SS-12-32-xx
• Compatible with PTFE elements: PT-12-32-xx
• Replace 'xx' with required grade (e.g. 50C, 25, 03)
Body material:
Seat:
Working pressure:
Temp range:
Size:
Volume:
SS316L
Viton
7 Bar
100 max.
110
29
Connection A size:
Connection A type:
Connection A gender:
Connection B size:
Connection B type:
Connection B gender:
Connection C size:
Connection C size:
Connection C type:
Connection C gender:
1/4"
NPT
female
1/4"
NPT
female
1/8'
NPT
female
