7088F4Y
HokeUltramite™ Fixed End Ball Valves 316 1/4"NPT-F 1/4"NPT-F
Uni-directional, High Cycle, Zero Leak Ball Valves
The Hoke 7088 Series ball valves are compact quarter-turn instrumentation valves designed for reliable shutoff service in demanding gas and liquid applications. Part of the Ultramite™ 70 Series, these valves feature a rugged welded body construction that enhances safety and structural integrity while preventing accidental disassembly during operation. The floating ball design provides bubble-tight sealing, low operating torque, and long cycle life under repeated use. Reinforced seat materials and dual stem sealing systems contribute to dependable leak-tight performance in both vacuum and high-pressure environments. Constructed primarily from 316 stainless steel, the series offers excellent corrosion resistance and compatibility with a broad range of industrial media. Typical applications include analyzer systems, sampling panels, process instrumentation, hydraulic systems, and high-pressure isolation service.
Body material:
SS316/316L
Connection A size:
Connection A type:
Connection A gender:
Connection B size:
Connection B type:
Connection B gender:
1/4"
NPT
female
1/4"
NPT
female
• Fixed end fittings prevent accidental disassembly, enhancing safety
• Oval trip-proof handle helps prevent accidental actuation
• Quarter-turn handle provides a visual indication of on/off valve position
• Floating ball provides pressure-assisted sealing and temperature wear compensation
• Encapsulated seats extend cycle life, reducing cost of ownership
• Check seals improve leak tightness, increasing seat life
• Special high-tolerance NPT thread ensures secure and leak-tight connections
