8DU316
Gyrolok Dielectric Union 316 1/2"OD-F 1/2"OD-F
Connector Male
Gyrolok dielectric unions are tube fitting connectors designed to electrically isolate sections of tubing and piping systems while maintaining reliable leak-tight sealing performance. These fittings help prevent galvanic corrosion and stray current transfer in instrumentation and process applications. Available materials include 316 stainless steel, Brass, Monel, Hastelloy, Inconel, Incoloy, Duplex, Super Duplex, and Titanium.
Body material:
SS316/316L
Connection A size:
Connection A type:
Connection A gender:
Connection B size:
Connection B type:
Connection B gender:
1/2"
OD
female
1/2"
OD
female
• Molded thermoplastic insulators provide electrical resistance exceeding 7.0 x 10⁸ Ω at 70°F (21°C) and 50% relative humidity.
• 90 durometer Viton® O-ring and virgin TFE back-up washer ensure reliable fluid containment.
• Pressure rated up to 4000 PSIG at 70°F (27,580 kPa at 21°C).
• Operating temperature range from -40°F to +200°F (-40°C to +93°C).
• Designed to maintain appropriate flow for line size with specific orifice dimensions.
